Sediment filters
Used for the removal of sediment & particles
Wound slim filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Wound polypropylene yarn | 10" | 500 | 0.5, 1 |
| Wound polypropylene yarn | 10" | 1,000 | 5, 10 & above |
| Wound polypropylene yarn | 20" | 1,000 | 1 |
| Wound polypropylene yarn | 20" | 1,000 | 1 |
| Wound polypropylene yarn | 30" | 3,000 | 0.5, 1, 5 & above |
| Wound polypropylene yarn | 40" | 4,000 | 0.5, 1, 5 & above |
Wound jumbo filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Wound polypropylene yarn jumbo | 10" | 1,500 | 0.5, 1 |
| Wound polypropylene yarn jumbo | 10" | 3,000 | 5, 10 & above |
| Wound polypropylene yarn jumbo | 20" | 3,000 | 0.5, 1 |
| Wound polypropylene yarn jumbo | 20" | 6,000 | 5, 10 & above |
Spun slim filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Spun polypropylene | 10" | 500 | 0.5, 1 |
| Spun polypropylene | 10" | 1,000 | 5, 10 & above |
| Spun polypropylene | 20" | 1,000 | 1 |
| Spun polypropylene | 20" | 1,000 | 1 |
| Spun polypropylene | 30" | 3,000 | 0.5, 1, 5 & above |
| Spun polypropylene yarn | 40" | 4,000 | 0.5, 1, 5 & above |
Spun jumbo filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Spun jumbo polypropylene | 10" | 1,500 | 0.5, 1 |
| Spun jumbo polypropylene | 10" | 3,000 | 5, 10 & above |
| Spun jumbo polypropylene | 20" | 3,000 | 0.5, 1 |
| Spun jumbo polypropylene | 20" | 6,000 | 5, 10 & above |
Bacteria & Sediment filters
Provides ultrafiltration for removal of fine particles & micro-organisms & bacteria thus reducing risk of water bourne diseases. Some can be cleaned by scrubbing.
Pleated slim filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Pleated polypropylene | 10" | 500 | 0.22, 0.45 & above |
| Pleated polypropylene | 20" | 1,000 | 0.22, 0.45 & above |
Pleated jumbo filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Pleated jumbo polypropylene | 10" | 500 | 0.22, 0.45 & above |
| Pleated polypropylene | 20" | 1,000 | 0.22, 0.45 & above |
Ceramic filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Ceramic | 10" | 500 | 0.9 |
Most organic chemical, chlorine, insecticides, pesticides, herbicides, taste, odor & inhibits growth of within the filters
Granular Activated Carbon slim filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Granular Activated Carbon | 10" | 500 | 5 |
| Granular Activated Carbon | 20" | 1000 | 5 |
Granular Activated Carbon jumbo filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Granular Activated Carbon jumbo | 10" | 1500 | 5 |
| Granular Activated Carbon jumbo | 20" | 3000 | 5 |
Block Activated Carbon slim filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Block Activated Carbon | 10" | 500 | 5 |
| Block Activated Carbon | 20" | 1000 | 5 |
Block Activated Carbon jumbo filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Block Activated Carbon jumbo | 10" | 1500 | 5 |
| Block Activated Carbon jumbo | 20" | 3000 | 5 |
Hardness filters
A Water Softener is an ion exchange system that works by removing calcium & magnesium ions that make up hard water.
Resin slim filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Resin | 10" | 500 | - |
| Resin | 20" | 1000 | - |
Iron removal filters
This filter is an oxidizing agent designed for iron reduction in water, it oxidizes the ferrous Fe2+ to Ferric Fe3+, the Manganese is oxidized from Mn2+ to Mn4+, as the water flows through the media filtration, the oxidized iron and manganese is filtered out through the media
Katalox slim filters
| Type | Size | Max flow rate | Micron(Mesh) |
|---|---|---|---|
| Katalox | 10" | 500 | - |
| Katalox | 20" | 1000 | - |
